In your operation
Reduce walking between storage locations
P800R brings the rack to the operator so picking can happen at a workstation. It transports the inventory fixture; it does not grasp individual products.
Product
Geek+Movers & material handling
Geek+ P800R
A shelf-carrying robot in Geekplus's goods-to-person system, moving configured racks between storage positions and picking workstations.
- Payload
- 1,000 kg
- Lift
- 60 mm
- Loaded speed
- 1.6 m/s
Price on requestSAR
Own the equipment. Configuration and project scope are confirmed in your quote.
Compare productsIndicative budget only, not a confirmed Saudi retail offer. Configuration, freight, tax, deployment and service are confirmed in your quotation. Rental and RaaS figures are planning estimates.
Product profile
Bring storage racks to picking stations
Load moving
- Product type
- Movers & material handling
- Best for
- Warehousing & logistics
- Environment
- Indoor
What it does for your operation
Task performance
Lift the configured rack from below
The standard P800R carries up to 1,000 kg and lifts a compatible rack by 60 mm. Rack mass and goods together must stay within the load limit.
Configuration
Fit the robot beneath the storage rack
The standard P800R is 275 mm high and lifts the rack from below. Match rack clearance, pickup geometry and load footprint to this platform when laying out storage.
Connected systems
Coordinate rack movement and order work
The Geekplus software suite includes robot management and warehouse execution modules. The required modules and WMS data exchange are specified as part of the system.
Site fit
Design storage and workstations together
Plan racks, charging positions and picking stations around the SKU demand and order mix. Floor condition and operator handoffs influence how many rack movements the system can complete.
Operating conditions
IndoorWill it work at your site?
Access & operating limits
- Installation
- Compatible mobile shelves, pick stations, charging and fleet software.
- Navigation
- Floor QR-code markers form part of the route layout.
- Floor limits
- Survey floor flatness, joints and level changes against the selected P800R installation specification.
- Load and safety
- Validate shelf clearance, load stability, robot zones and workstation handover.
Supplied within a goods-to-person solution with compatible shelves, stations and fleet software. Confirm rack layout, load dimensions and operating capacity.
Typical applications
Load moving
Systems & infrastructure
Integrations and compatibility.
Manufacturer-documented connections and compatible equipment. Building interfaces are checked against your installation.
Geekplus RMS and WES
Robot management and warehouse execution, with the required modules and WMS data exchange defined for the installation.
Technical specifications.
- Model
- P800R, standard configuration; not P800R V6
- Maximum payload
- 1,000 kg
- Lift
- 60 mm
- Dimensions
- 1,090 × 830 × 275 mm
- Maximum speed, loaded
- 1.6 m/s
- Maximum speed, unloaded
- 2 m/s
- Navigation
- Inertial and floor-code visual navigation
Before you decide.
What is the standard P800R's payload?
Maximum payload is 1,000 kg, including the rack and its contents. The lower-profile P800R V6 is a different configuration.
Does it pick items off shelves?
No. It carries a compatible rack to the picking workstation, where a person or separate automation handles the items.
